AFR Stage 1 Small Block Ford Hydraulic Roller Camshaft - Billet 8620 Steel Core

AFR 6001
Air Flow Research, the authority in high-performance CNC cylinder heads for over 55 years, proudly introduces its latest innovation: custom camshafts for the iconic Small Block Ford 302 and 351 Windsor. Specifically engineered to complement the airflow and velocity balance of AFR’s Renegade CNC-ported and Enforcer As-Cast cylinder heads, the Stage 1 cam is designed to deliver crisp throttle response, strong low-end torque, and a broad mid-range powerband — perfect for high-performance street and street/strip combinations.

Developed in collaboration with Andrews Products, renowned for championship-winning camshaft design and precision grinding, these new profiles further AFR’s commitment to giving American muscle the performance it was built for.
Pricing: $449.00

Qty:
Free Basic Shipping

Description

Camshaft Specs:
Cam Style: Retro Fit Hydraulic roller.
Camshaft Use: Strip/high-RPM
Intake/Exhaust Duration at .050-inch Lift: 216/224
Valve Lobe Lift: .345
Valve Lift with Factory 1.6 Rocker Arm Ratio: 0.544int./.0552exh.
Lobe Separation (degrees): 112
Camshaft Gear Attachment: 1-bolt
Valve Springs Required: Yes

Cam Features:
Upgraded to industry-preferred 8620 steel for superior strength and durability
• Ideal for high-RPM builds, power adder applications, and aggressive street use
• Exceptional wear resistance for long-term valvetrain stability
• Improved core hardness allows for more precise and consistent grinds
• Excellent response to heat-treating for a hardened surface without sacrificing ductility
• Trusted in top-tier racing environments—now included in every AFR camshaft
