Aeromotive Extreme Flow EFI Regulator W/ Dual Port - Black Anodized

AEI-13134
Extreme Flow EFI Regulator Designed for use with Eliminator, Pro Pump, and Dual A1000 fuel system. Compact 2-port body with dual AN-10 inlet/outlet ports and one AN-10 return port. 0.313 High Flow Valve/Seat, able to handle 3-9 GPM Fuel Pump. Dual Springs expand operating pressure range while maintaining a low profile and reduced weight. Standard spring (installed) supports 30-75 PSI base fuel pressure. High pressure spring (included) supports 75-120 PSI base fuel pressure. Supports vacuum and boost reference on a 1:1 ratio with PSI.
Pricing: $288.95

Qty:
Free Basic Shipping

Description

Features:
Extreme Flow Design ideal with Eliminator, Pro-Pump, Dual A1000 and Brushless 3.5 and 5.0 Gear Pump fuel systems.
Suitable for Mechanical pumps up to 6.0 GPM.
Compact, 2-Port Body with dual ORB-10 inlet/outlet ports and one ORB-10 return port.
High Flow 0.313" Valve/Seat, optimized for larger electric fuel pumps in the 2.5-6.0 GPM flow range.
Dual Springs expand pressure range while maintaining a low profile and reduced weight.
Standard spring (installed) supports 30-75 PSI base fuel pressure.
High Pressure spring (included) supports 75-120 PSI base fuel pressure.
Systems where an electric pump is desired and where base pressure exceeds 70-PSI should run two pumps of similar flow rate, in series.
This product is not legal for sale or use on emission-controlled vehicles except when used on a dedicated race vehicle.
Vacuum and boost reference on a 1:1 ratio.
Compatible with gasoline, ethanol and methanol.

Details

  • AEI-13134
  • AEI-13134
  • Aeromotive
  • New

Shipping Information

  • Item Requires Shipping
  • 1.3 lbs.
  • W5.5000” x H2.7500” x L5.5000”
  • Free Basic Shipping
