CVF Chevy Small Block Mid-Mount Serpentine System with AC, Power Steering & Alternator (All Inclusive) - Polished

350-WRAPTOR
All Inclusive WRAPTOR 8 Rib Serpentine System for Chevy Small Block engines with 160 Amp alternator, GM Type II Power Steering Pump and Peanut Style AC compressor. CVF Racing's 8 Rib Serpentine pulleys increase grip, reduce stretching and prevent slipping compared to traditional 6 Rib designs. Spring loaded tensioner ensures proper tension during hard acceleration and deceleration while compensating for belt stretch. Places alternator on the driver's side above the power steering pump.

Note: This kit will fit 283, 350, and 400 Small Block Chevy Engines.

See the blue product options button to configure your system!
Was: $1,895.00
Sale: $1,795.00
Save: 5%
Save: $100.00

Customize Your Item

- Billet Thermostat Housing Option -
- System Configurations -
- Alternator Options -
- Finish Options -
- Cooling Fan Options -
- Reservoir Options -
- Power Steering Line Kit Options -
- Power Steering Pump Options -
Qty:
Free Basic Shipping

Description

Kit Includes (All Inclusive):
High Flow Aluminum Water Pump
160 Amp Chrome 1-Wire CS130 Alternator
Chrome Plated AC Compressor*
AC Compressor Clutch Cover*
Chrome Plated Aluminum GM Type II Power Steering Pump*
Premium 8 Rib Belt
Water Pump Pulley & Cover
Crank Pulley
Crank Pulley Spacer
Alternator Pulley & Cover
Power Steering Pulley*
One Piece Billet Aluminum Bracket
Universal Alternator Fan
All Mounting Hardware

* = parts that change depending on your configuration selection

Specs:
Power Steering Included: Yes (can be removed using the product options)
AC Included: Yes (can be removed using the product options)
Mounting Position: Mid-Mount
Finish: Polished or C3 Clear Coat
Belt Type: Serpentine 8 Rib
Water Pump Type: Mechanical
Water Pump: Short
Water Pump Rotation: Reverse
Engine Fitment : 283, 350, and 400 Small Block Chevy Engines

Application Notes:
Works with either Mechanical or Electric fuel Pump
Works with either Mechanical or Electric fan (may require long fan spacer)
Works with either Standard or Camel Hump / Fuelie Heads
Power Steering Lines from pump to reservoir not included
Reverse Rotation Water Pump
Compatible with Hydroboost ($275 option)
