A&A Corvette C6 Vortech Supercharger Mounting Bracket

AAC6BR
New A&A mounting brackets for your C6 supercharger needs. Featuring a state of the art bracket/tensioner assembly with unsurpassed belt wrap on the supercharger pulley and crankshaft pulley. Standard polished finish, or black anodized option. Standard fitment for V3-Si / YSi Vortech Head Units, or Procharger Head Units for an extra charge.

Was: $1,299.00
Sale: $999.00
Save: 23%
Save: $300.00

Customize Your Item

- Finish Options -
Qty:
Free Basic Shipping

Description

Each plate is machined on both sides to assure absolute flatness and accuracy. Super strong bracing, Grade 8 hardware, all steel pulleys with dual bearings, stainless or aluminum stantions for proper bearing support and our adjustable billet tensioner are all standard. A&A brackets are also set up to use 6 or 8 rib drive pulleys without modification, right out of the box.

Each tensioner is machined from 9.6 pounds of 6061 Aluminum bar. The shaft is precision machined 4340 Chromoly steel. The tensioner rotates on German manufactured bearings that are precision fit much like an engine bearing. The bores are set for a certain amount of “crush” so that the shaft to bearing clearance is within the range specified by the bearing manufacturer.

The brackets have 3 internal spring settings. A 1000 HP drag racer obviously needs more spring pressure than a 600 HP daily driver, so this can be accomplished with just one tensioner. A&A even has an optional spring for super high horsepower drag racers. There is also a “lock pin” so the tensioner can be rotated to the slack position and locked in place. This is a huge help when installing a belt, changing an alternator etc. Fighting the spring tensioner is a thing of the past.

Each one is hand assembled at our facility and checked for proper operation and spring tension with a digital torque meter. Nobody else does that but A&A!
