Injector Dynamics ID1300XDS Fuel Injectors 1988-1999 Toyota Celica All-Trac / 3S-GTE - For Top-Feed Fuel Rail Conversations (14mm)

Included: 4 Injector Dynamics ID1300XDS fuel injectors. The photo is an example of a similar set.

The ID1300XDS is an all new injector, designed in partnership with Bosch Motorsport. This collaboration has given us the ability to design a high flow injector with characteristics specific to the needs of the motorsport tuner. The ID1300x² was designed with alternative fuels in mind, and was originally the only performance injector available with all stainless internals. It is compatible with all known fuels, and will stand up to the corrosive nature of alcohol better than any injector on the market.

These Injector Dynamics fuel injectors will fit many applications, including, but not limited to:

1988-1999 Toyota Celica All-Trac / 3S-GTE - 14mm - Top Feed

Specifications
Nominal Flow Rate – 1335cc/min @ 3.0 Bar (43.5 psi) Using Iso Octane at 52 Degrees C (125 Degrees F)
Maximum Differential Fuel Pressure – 7.0 Bar (101.5 psi)
Fuel Compatibility – Compatible With All Known Fuels
Electrical Connector – US EV6 / USCAR
Injector Body Design: Metal and composite plastic
O-Rings Included: Yes, on the injectors
Length of injector from o-ring to o-ring: 60mm
Diameter of top o-ring / fuel rail bore: 14mm
Diameter or style lower o-ring or cushion: 14mm
