Injector Dynamics ID1050XDS Fuel Injectors 1988-2002 Nissan 240SX S13 / S14 / S15 / SR20DET - For Top-Feed Fuel Rail Conversations (14mm)

Included: 4 Injector Dynamics ID1050XDS fuel injectors. The photo is an example of a similar set.

The ID1050XDS is the evolution of the ID1000, and the latest addition to the X-Series. It is the most recent offering from the partnership of Injector Dynamics and Bosch Motorsport, and is the result of lessons learned during development of the ID1300x, and ID1700x. Like the ID1300x and ID1700x, the ID1050x is not a modified production component. It is a built to spec motorsport injector, offering optimization of critical operating parameters important to you, the motorsport tuner. Compared to the original ID1000, the ID1050x offers numerous improvements, and is sure to become the new reference.

These Injector Dynamics fuel injectors will fit many applications, including, but not limited to:

1988-2002 Nissan 240SX S13 / S14 / S15 / SR20DET *Top-Feed Conversion Required*

Specifications
Typical Flow Rate in CC per minute: 1065cc/min @ 3.0 Bar (43.5 psi) Using Gasoline at 52 Degrees C (125 Degrees F)
Maximum Differential Fuel Pressure – 10.0 Bar (145.0 psi)
Fuel Compatibility – Compatible With All Known Fuels – (Designed Specifically for Alternative Fuels)
Electrical connector type: USCAR
Injector Body Design: Metal and composite plastic
O-Rings Included: Yes, on the injectors
Length of injector from o-ring to o-ring: 60mm
Diameter of top o-ring / fuel rail bore: 14mm
Diameter or style lower o-ring or cushion: 14mm
