CVF Reaper Dodge Hemi 5.7L/6.1L/6.4L 10-Rib FEAD System For Whipple Inverted 3.0L With Alternator, AC & Power Steering - Polished
This system includes all the brackets and accessories if you're not running AC or Power Steering see the product options to remove those items.
Note: Does not include any Whipple 3.0L Inverted Headunits, available in the product options or see PN: WK-3020HR-30. Requires harmonic dampener. All engines REQUIRE a car timing cover. Dodge Ram and Durango both came w/ a different style timing cover.
*Notice, this system includes your options of supercharger pulley, which go from 2.4"-4" pulley sizes.
**There are many product options, click on the blue "choose the product options" button to configure your system!
Description
Wraptor System Includes:
160 AMP Chrome 1-Wire CS130 Alternator*
Chrome Plated Peanut Style Compressor
AC Compressor Billet Clutch Cover
Premium 8 Rib Belt*
Premium 10 Rib Belt*
Billet Water Pump Pulley w/ Decorative Cap*
Billet Crank Pulley*
Billet Alternator Pulley w/ Decorative Cap*
AC Bracket*
Power Steering & Alternator Bracket*
Universal Billet Alternator Fan*
Spring Loaded Tensioner w/ Decorative Cap*
Idlers w/ Decorative Caps*
GM Type 2 Power Steering Pump w/ Billet Remote Reservoir
As Cast Aluminum High Flow Water Pump*
Supercharger Hub*
Supercharger Pulley*
Stainless Steel Hardware*
Clear Anodized Spacers
Billet Water Neck
*Changes with your configuration choice
Compatible Upgrades:
Option to add a Whipple Head Unit available
Application Notes:
ATI balancers are available from ATI and compatible with any Gen III Hemi with VCT (2009+). ATI Part Numbers: 918459 or 918486.
All engines REQUIRE a car timing cover. Dodge Ram and Durango both came w/ a different style timing cover.
Fits Whipple 3.0L Superchargers (Durango/Charger) WK-3020HR-30
Details
- G3HW3-RP
- G3HW3-RP
- CVF Racing
- New
Categories
Shipping Information
- Item Requires Shipping
- 30.0 lbs.
- W20.0000” x H20.0000” x L10.0000”
- Free Basic Shipping
