CVF Reaper Dodge Hemi 5.7L/6.1L/6.4L 10-Rib FEAD System For Whipple Inverted 3.0L With Alternator, AC & Power Steering - Polished

G3HW3-RP
The CVF Racing Reaper Serpentine System is a premium dual belt drive solution engineered specifically for Gen III Dodge Hemi 5.7L and 6.1L engines running the Whipple 3.0L supercharger. This high-performance serpentine system features a dedicated 10 rib supercharger belt and separate 8 rib accessory drive, delivering superior belt grip, improved boost stability, and maximum reliability for extreme horsepower builds approaching 1500 HP

This system includes all the brackets and accessories if you're not running AC or Power Steering see the product options to remove those items.

Note: Does not include any Whipple 3.0L Inverted Headunits, available in the product options or see PN: WK-3020HR-30. Requires harmonic dampener. All engines REQUIRE a car timing cover. Dodge Ram and Durango both came w/ a different style timing cover.

*Notice, this system includes your options of supercharger pulley, which go from 2.4"-4" pulley sizes.

**There are many product options, click on the blue "choose the product options" button to configure your system!
Was: $3,595.00
Sale: $3,395.00
Save: 6%
Save: $200.00

Customize Your Item

- Alternator Options -
- Polished Style -
- Power Steering Line Kit Options -
- Water Pump Style -
- SC Pulley Type -
- Crank Pulley Type -
- Power Steering Options -
- System Configurations -
- Supercharger Options -
- Throttle Body Adapter Options -
- Tensioner Options -
Qty:
Free Basic Shipping

Description

Wraptor System Includes:
160 AMP Chrome 1-Wire CS130 Alternator*
Chrome Plated Peanut Style Compressor
AC Compressor Billet Clutch Cover
Premium 8 Rib Belt*
Premium 10 Rib Belt*
Billet Water Pump Pulley w/ Decorative Cap*
Billet Crank Pulley*
Billet Alternator Pulley w/ Decorative Cap*
AC Bracket*
Power Steering & Alternator Bracket*
Universal Billet Alternator Fan*
Spring Loaded Tensioner w/ Decorative Cap*
Idlers w/ Decorative Caps*
GM Type 2 Power Steering Pump w/ Billet Remote Reservoir
As Cast Aluminum High Flow Water Pump*
Supercharger Hub*
Supercharger Pulley*
Stainless Steel Hardware*
Clear Anodized Spacers
Billet Water Neck

*Changes with your configuration choice

Compatible Upgrades:
Option to add a Whipple Head Unit available

Application Notes:
ATI balancers are available from ATI and compatible with any Gen III Hemi with VCT (2009+). ATI Part Numbers: 918459 or 918486.
All engines REQUIRE a car timing cover. Dodge Ram and Durango both came w/ a different style timing cover.
Fits Whipple 3.0L Superchargers (Durango/Charger) WK-3020HR-30
