FAST LSXR 102mm Intake Manifold Big Mouth Chevy LS1/LS2/LS6 - Cathedral Port

FST-146302B
Constructed from the same advanced polymer material as the LSX™ 92mm Intake Manifold, the LSXR™ offers a host of benefits over aluminum aftermarket intakes, including lighter weight, increased strength and improved heat dissipating characteristics. While the LSXR™ features a 102mm air inlet that is perfectly suited to the FAST™ Big Mouth 102mm Throttle Body™, it can also be used with stock or aftermarket 90mm or 92mm throttle bodies. Other features include integrated nitrous bungs and perfect bolt-on fitment that allows the use of factory accessories without modification or clearance concerns.

Notes: This is a 3-piece unit designed for the big mouth 102 mm throttle body or a stock throttle body with adapter. For cathedral port heads. Gaskets not included.

*This intake manifold is 50 State Legal CARB EO# D-279-10
Was: $1,252.95
Sale: $1,152.95
Save: 8%
Save: $100.00

Qty:
Free Basic Shipping

Description

Features:
LSXR intake w/ 102mm opening & added refinements
Includes stainless steel bolts, threaded insert throttle body mounts & mounting hardware
Incorporates high-quality polymer materials, which resist “heat sink” effect of aluminum
Maximizes potential of other popular engine performance upgrades such as cylinder heads
Improved throttle body sealing flange & o-ring gasket
50 state legal under C.A.R.B. E.O. #D-279-10

Specs:
Cylinder Head Configuration: LS1/LS2/LS6 (Cathedral Port)
Fuel Injection Style: Multi-port
Basic Operating RPM Range: 1,800-6,000
Throttle Body Bore Size: 102mm

Details

  • FST-146302B
  • FST-146302B
  • FAST
  • New

Categories

Shipping Information

  • Item Requires Shipping
  • 25.0 lbs.
  • W12.0000” x H12.0000” x L24.0000”
