FIC 1650cc High Z Flow Matched Fuel Injectors for LS1 & LS6 Engines - Set of 8

Included:
8 - FIC 1650cc Denso High Impedance Fuel Injectors (PN: IS301-1200H)

*EV1 Pigtails Available

Specifications:
Bottom O-ring Outer Diameter 14mm
Cylinder Quantity 8
Height 64mm
Impedance High-Z
Top O-ring 14mm

Fuel Injector Clinic's 1650cc/min high impedance injector is the largest high impedance injector compatible with all race fuels and has excellent idle performance in street driven cars while still providing enough fuel to support higher horsepower output on both E85 and gasoline. The 1650cc high impedance injector can be used with any fuel type based on the stainless alloy valve construction. It is compatible with pump gasoline, E85, Q16 or VP Import or any other MTBE oxygenated fuels. Superior short pulse width control and state of the art matching make these injectors easy to tune and provide great drivability.

Fuel Injector Clinic injectors are flow tested and rated at 43.5psi (3Bar) at 90deg F fuel temperature using CF-16B calibration fluid. Fuel Injector Clinic injectors are set up to and include all o-rings needed to fit the factory application for the listed vehicle. If you are using aftermarket or other unusual setups please contact us prior to placing your order to make sure you receive injectors that fit properly.

Every injector is covered against failure caused by defects in original manufacture by our lifetime warranty.

Horsepower supported:
WHP on E85 at 43psi 90%DC NA 1479.56
WHP on E85 at 43psi 90%DC Supercharged 1345.05
WHP on E85 at 43psi 90%DC Turbo 1232.97
WHP on E85 at 58psi 90%DC NA 1708.89
WHP on E85 at 58psi 90%DC Supercharged 1553.54
WHP on E85 at 58psi 90%DC Turbo 1424.08
WHP on Gas at 43psi 90%DC NA 1923.43
WHP on Gas at 43psi 90%DC Supercharged 1748.57
WHP on Gas at 43psi 90%DC Turbo 1602.86
WHP on Gas at 58psi 90%DC NA 2221.56
WHP on Gas at 58psi 90%DC Supercharged 2019.60
WHP on Gas at 58psi 90%DC Turbo 1851.30
