Cadillac CTS-V 2016-2019 GForce Performance Renegade Axles, Left and Right

The 16+ CTS-V axles reuse the factory inner differential stub shafts. We use a billet adapter that bolts to the factory inner stub shaft flange, and this adapter allows us to bolt our CV up directly. We still use our billet outer stub shaft to fit up to the factory 33 spline wheel hub.

Our average 16+ CTS-V customer is around 750-800hp, with some over 1000hp. Important to note that any axle can fail at a lower power level due to wheel hop or misuse. The listed numbers should not be an expectation, but an idea for capability.

Features:
Anti-Wheel Hop Technology
Direct Bolt-In Fit and Finish
Billet Outer Stubs
Reuses Factory Inner-Stubs
Aircraft Grade Certified Alloys
CNC-Machined
Powder Coated Axles For Corrosion Protection
Black e-coat finish on inner and outer stubs to protect against harsh conditions without impeding spline engagement

*All 2016-2019 CTS-V axles are designed to work with the factory 31 spline differential and 33 spline wheel hubs

Damage Prevention
NO DRIVELINE COMPONENT IS BOMBPROOF! GForce does not put a power rating on any driveline components as there are entirely too many variables that can affect a driveline component other than just horsepower. We take great pride in building the strongest driveline components to fit certain applications, but it is important to know that YOU, the end customer, are responsible for proper installation and YOU, as the driver, are responsible for the lifespan of your axles or other driveline components.Most of the applications we are working with are heavy vehicles and we are often asking a lot of the driveline components, be it OEM or aftermarket. These heavier cars, paired with high torque levels make all driveline components more susceptible to failure due to small mistakes, such as wheel hop. Many customers understand that wheel hop, tire shake, tire skipping, tire chatter are all bad things but there is often a misunderstanding of how destructive it can really be. The heavier the vehicle and more torque the vehicle is making, the more your window of forgiveness begins to narrow. This can result in CV’s loosening prematurely and more severely, splined stubs and axle bars twisting or shearing, which is NOT a fault of the axle. So please use your best judgement when driving in any given scenario, be it on the track or the street.

It is worth noting that most wheel hop related issues rarely cause an immediate failure, with certain exceptions. The result of repeated cycling torque spikes will often weaken the material of a given component such as an axle bar or stub shaft. Then each subsequent hit will continue to weaken the component until it fails completely. If you know that you have driven through a particularly abusing situation, it would be wise to pull the axles and assess the splines of the inner and outer stub shafts as a maintenance procedure. If they have started to twist or shift, then you might be able to prevent a more catastrophic failure. We encourage all end users to read up on the appropriate measures that they can take to help prevent wheel hop with their specific vehicle. This can be anything such as aftermarket bushings, shocks, springs, control arms, tire type, or excessively low tire pressure. Two of the most fundamental pieces we look at to help control rear end movement and prevent wheel hop start with the cradle and differential bushings. Both of these bushing sets are often very soft from the factory and although they provide smooth ride quality, they allow a considerable amount of movement in a performance scenario. Which can lead to a number of concerns or issues.

If you have any further questions please email us at [email protected]

Lowered Vehicle Information
GForce axle shafts were manufactured based on OEM suspension. Aftermarket shocks, control arms, etc. may present clearance issues. If CV boots have clearance issues, low profile boots can be purchased at an upgraded cost. The low profile boots reduce the amount of available axle angle in comparison to the standard boots, so they are not ideal for lowered or high axle angle vehicles. If you have questions or would like to add low profile boots to your axles, please contact us for more information.

Maintenance Information
All driveline components will fatigue or wear over time depending on how the vehicle is driven and what level of performance is demanded from them. CV joints are a wear item and will see wear over time, but with our current design, axles can be sent in for service. So boots, fasteners, and CV assemblies can be serviced without scrapping the complete axle assembly. It is up to each customer to establish their own maintenance intervals based upon the manner in which their car is driven. Individual inner or outer splined stubs and axle bars can be replaced as well if they twist or are damaged due to wheel hop or simply from power levels exceeding capability of the material.
