Vortech V-3 Si-Trim Heritage Series Supercharger Head Unit Only - Satin

2F228-010H
This is a Vortech Supercharger Head Unit only. These can be used on vehicles that can support up to 22 psi of boost and is capable of producing 775 horsepower!
The classic is new again. Back by popular demand, the original Vortech V-1 gearset from 1990 is now available with modern efficiency, in a self-lubricated transmission package. The Heritage Series units feature the same self-contained lubrication system as the normal V-3 units, and come with an attached oil drain extension so the unit does not have to be removed for servicing. The V-3 Heritage Series Si-Trim Supercharger is capable of up to 775HP on modified vehicles. Extraordinary 78% peak efficiency. Ideal for latest generation of improved breathing, high-power street and strip engines.
Shipping: FREE continental USA ground shipping on ALL Vortech Superchargers!
Pricing: $3,501.99

Customize Your Item

- Head Unit Finish Options -
- Head Unit Rotation Options -
Qty:
Free Basic Shipping

Description

Performance Specs:
Internal Step-Up Ratio: 3.5:1
Max Speed: 52,000 RPM
Max Boost: 22 PSI
Max Flow: 1,150 CFM
Max Power: 775 HP
Peak Efficiency: 78%

Performance specs apply to units equipped with standard gearcase.

Dimensions
Discharge OD: 2.75"
Inlet OD: 3.5"
Discharge ID: 2.38"
Inducer Diameter: 3.1"

Vortech Dealer information
Not any shop can become an Authorized Vortech Installing Dealer; you need to be knowledgable in both naturally aspirated and boosted high performance vehicles, and have the staff to support customers with both in store and phone support. Vortech is very strict about who they allow as dealers. Most online only or mail order companies are unable to qualify as dealers, but you are welcome to stop by our shop to talk about your application or view our supercharger kits. TREperformance has been building high performance vehicles for over 15 years, everything from simple engine upgrades to 1,000 horsepower drag cars. We have been selling superchargers and building blown motors for over a decade, so you know the dealer you are buying from has the knowledge to get you the right kit for your application.

Details

Categories

Shipping Information

  • Item Requires Shipping
  • 35.0 lbs.
  • W15.0000” x H12.0000” x L12.0000”
  • Free Basic Shipping
  • This item ships in its own box.
  • FREE continental USA ground shipping on ALL Vortech Superchargers!
