Kenne Bell 2007-2014 Ford Shelby GT500 5.4L / 5.8L - Supercharger 3.6LC Upgrade Kit

TS1000-SHUPGD36
This is a Kenne Bell Supercharger Upgrade Kit with a Black Powdercoated Mammoth 3.6LC Twin Screw head unit and stock 10 rib pulley setup for the 2007-2014 Ford Shelby GT500 5.4L / 5.8L and is a direct replacement for the 2.8L & 3.2L kit with all parts included! This system includes a liquid hose kit, wire loom bracket, pulley (your choice), 60mm idler ('07-'14), belt (for stock 7.1" crack pulley), bolts, 3/8" hose and 3/8" 90°. This is the tuner kit which will require a custom tune done locally after you install the kit, and does not include a fuel system, programmer, or tuning. If you have other modifications such as headers, midpipe, camshaft, etc. then look at the "TUNER" kit instead. Kits include your choice of polished or black polished supercharger and drive.

Note: see the blue product options button for your choice of Polished or Black Polished headunit finish.
Shipping: FREE continental USA ground shipping on ALL Kenne Bell Supercharger Systems!
Was: $5,299.00
Sale: $4,899.00
Save: 8%
Save: $400.00

Customize Your Item

- Head Unit Finish Options -
- Deduction Option -
Qty:
Free Basic Shipping

Description

There are many options available for Kenne Bell Supercharger kits. If you have any questions please email [email protected] or call 760-586-5617.

DETAILS:
Mammoth 3.6LC billet twin screw supercharger head unit, Includes your choice of Polished or Black Polished Headunit & Drive Finish
Direct replacement for the 2.8L & 3.2L kit
93mm Real Cool Air Kit. Up to 41° cooler oil temps.
Bigger and more is better. 20% larger Kenne Bell Hi Density Intercooler concept uses 30% more cooling rows and fins for increased cooling efficiency
Belt Drive System: Stock 10 rib
Fuel Pump Booster Supplied: NONE Supplied
Fuel Injectors Supplied: NONE Supplied
Computer/Ignition Mods.: NONE Supplied
System is 100% complete with OEM quality and appearance
No Internal Modifications Required
This system includes your choice of Polished or Black Polished Finish see the blue product options button.

FEATURED DETAILS:
• Largest displacement 3L and 4L billet Twin Screws.
• 4x6 lobe rotors vs. 3x5 and 4x4 for competition
• Patented Liquid Cooled for cooler air charge / oil temps, higher RPM, boost and HP.
• Patented Spring Bypass
• Patented SPE (Seal Pressure Equalizer) for longer seal life. Also protects bearings from alcohol injection.
• Highest cfm inlet (Gimme 5). 2073 cfm vs 1850 (best competition)
• Largest/highest cfm Shelby throttle bodies available
• Largest Inlet Manifolds (168MM X 79MM vs 148MM x 66MM)
• Lowest PC (engine HP required to drive supercharger)
• All billet construction for durability
• Industry leading 2000HP rated Hi Density Intercooler (optional)
• 3.6, 4.2, 4.7LC fits under hood of Shelby Super Snake with drop mounts, included in complete kits, $119 extra in upgrade kits.
• Standard hoods will require K Member spacers and drop mounts, along with removal of the hood pad and possible trimming of hood support structure depending on the vehicle for clearance.
• Most flexible kit design. Easy to “step up” for racing or “dial down” for street with easy pulley change or Kenne Bell bolt ons.
• Largest 168mm Manifold for most HP, lowest parasitic losses and coolest air charge.
• Standard “Mammoth” 168mm Inlet Manifold accepts exclusive Kenne Bell 168mm Mammoth 2150 and 2350 Throttle Bodies.
• BIG BORE™ 2.8, 3.2, 3.6, 4.2, 4.7 (2.0 PR).
• Billet anodized or polished case vs. painted cast aluminum.
• Largest selection (3.2, 3.6, 4.2, 4.7)
• Kenne Bell Flash Tuner included with each kit.
• Exclusive Kenne Bell Dual BOOST-A-PUMP™ included with all kits. Larger pumps, fuel rails, lines etc. not required up to 1000HP.
• Smog Legal. EGR etc. not removed.
• Tested by Muscle Mustangs & Fast Fords and 5.0 Mustang Magazine.
• Quick easy install.
• Complete kit. No cobbling together a grab bag of parts and then paying a tuner to make it all work.

TREperformance is an Authorized Installing Dealer of Kenne Bell Superchargers.
12 Month warranty direct from KB
Custom made and shipped direct from KB in 2-4 weeks

Kenne Bell Dealer information
Kenne Bell is very strict about who they allow as dealers. Dealers must have experience with high performance forced induction applications and provide excellent customer service and application advice. Most online only or mail order companies are unable to qualify as dealers, but you are welcome to stop by our shop to talk about your application or view our supercharger kits.
