Trick Flow 420 HP Super 23 Top-End Engine Kits for Small Block Chevrolet

TFS-K314-420-395
Serious horsepower solutions.

Trick Flow® has done all of the tweaking and tuning with these engine kits for small Chevy, so you can get dyno-proven horsepower with no guesswork. Based around the dyno-proven Trick Flow® Super 23® cylinder heads, these kits scream performance. These kits include everything you need to give your street or bracket engine a maximum performance makeover! These kits feature a Trick Flow® hydraulic camshaft with a 228/234 degree duration at .050, .480/.494 in. lift, with 1.5 ratio rockers and a 110 degree lobe separation.
Limited Supply: only 1 remaining
Was: $2,855.99
Sale: $2,655.99
Save: 7%
Save: $200.00

Qty:
Free Basic Shipping

Description

KIT/COMBO CONTENTS:


TFS-31400510 Trick Flow Rocker Arms, Stud Mount, Full Roller, Aluminum, 1.5 Ratio, Fits 3/8 in. Stud, Chevy, Small Block, Set of 16

TFS-31478500 Trick Flow Timing Chain and Gear Set, True Roller, Double Roller, Billet Steel Sprockets, Chevy, Small Block, Set

TFS-30410002 x2 Trick Flow Cylinder Head, Super 23® 195, Fast As Cast®, Assembled, 62cc Chambers, 1.470" Springs, Small Chevy, Each

TFS-21400001 Trick Flow Lifters, Hydraulic, for Flat Tappet Camshafts, Chevy 262-454, Set of 16

SUM-G001 Summit Cam Button Spacer, Aluminum, Chevy, Small Block, Each

SUM-G1792 Summit Camshaft Lock Plate, Steel, Black Oxide, Chevy, Kit

TFS-92000 Trick Flow Cylinder Head Bolt Kit, Hex Head, Chromoly Steel, Black Oxide Finish, Chevrolet 262-400, Each

TFS-21407850 Trick Flow Pushrods, 5/16 in. Diameter, 7.850 in. Long, 4130 Chromoly, 0.080 in. Wall, For Guideplates, Set of 16

TFS-31400915 Trick Flow Gaskets, Full Set, Chevy, Small Block Gen I, Set

TFS-31401001 Trick Flow Camshaft, Hydraulic Flat Tappet, Advertised Duration 284/290, Lift .480/.495, Lobe Sep. 110, Small Chevy, Each

Quantity: Sold as a kit.

Notes: Will not fit centerbolt-style intake manifolds. Kit includes camshaft lock plate and thrust button assembly. Standard base circle camshaft, verify clearance in stroker applications.

Camshaft Included: Yes
Duration at 050 inch Lift: 226 int./234 exh.
Advertised Duration: 284 int./290 exh.
Valve Lift with Factory Rocker Arm Ratio: 0.480 int./0.495 exh.
Intake Manifold Included: No
Timing Chain and Gears Included: Yes
Lifters Included: Yes
Gaskets Included: Yes
Cylinder Head Style: Assembled
Cylinder Head Material: Aluminum
Cylinder Head Finish: Natural
Combustion Chamber Volume (cc): 62
CNC-Machined Combustion Chamber: No
Intake Runner Volume (cc): 195cc
CNC-Machined Intake Runner: No
CNC-Machined Exhaust Runner: No
Intake Port Location: Standard
Exhaust Port Shape: D-port
Exhaust Port Location: Standard
Spark Plug Style: Angle
Intake Valves Included: Yes
Intake Valve Diameter (in.): 2.020 in.
Exhaust Valves Included: Yes
Exhaust Valve Diameter (in.): 1.600 in.
Valve Springs Included: Yes
Outside Diameter of Outer Spring (in.): 1.470 in.
Damper Spring Included: Yes
Number of Springs Per Valve: Single
Retainers Included: Yes
Retainer Material: Chromoly steel
Locks Included: Yes
Lock Style: 7 degree
Valve Stem Seals Included: Yes
Rocker Arms Included: Yes
Rocker Arm Style: Full roller
Rocker Arm Ratio: 1.5
Rocker Arm Studs Included: Yes
Rocker Arm Nuts Included: Yes
Rocker Arm Nut Thread Size: 3/8 in.-24
Guideplates Included: Yes
Guideplate Pushrod Size: 5/16 in.
Pushrods Included: Yes
Valve Covers Included: No
Valve Cover Mounting Style: Perimeter bolt
Accessory Bolt Holes Drilled: Yes
Valve Guides Included: Yes
Valve Guide Material: Bronze
Valve Seats Machined: Yes
Valve Seat Machine Style: 3-angle
Valve Seat Material: Tungsten
Steam Holes Drilled: No
Oiling Style: Through pushrod
Machined for O-Ring: No
Heat Crossover: Yes
