Honda Accord 550cc Fuel Injectors 1990-1995

PL9-550
These RC Engineering 550cc Low Resistance, Peak and Hold fuel injectors are flow matched and will fit every model, engine, type or style for the following vehicles:

1990-1995 Honda Accord

Part # PL9-550

Description

Included: 4 Honda style injectors, spacers/o-rings, and flow sheets. The photo is an example of a similar set.

Note:
1) OBD1 style injector clips are REQUIRED. If your vehicle still has the stock injector clips and needs OBD1 style injector clips, please select them from the drop down menu above - additional $19.95.


Size Calculation
To determine what size injectors you should use, please visit : RC Engineering's Technical Notes


Specifications
Flow Rate in CC per minute: 550CC/min @ 43.5 PSI
Flow Rate in LB per hour: 52LBS/HR @ 43.5 PSI
Resistance: 2.5 ohms
Voltage: 8-15 Volts, nominal 13.5 Volts
Amperage: Peak 4.0 Amps/ Hold 1.5 Amps
Pressure: Min 30PSIG/ Max 100PSIG
Part Number: PL9-550
Spacers/O-rings Included: YES
Warranty: 1 year warranty!


Shipping Information

  • Item Requires Shipping
  • 2.0 lbs.
  • W5.0000” x H5.0000” x L5.0000”
  • Free Basic Shipping
