Honda 310cc Fuel Injectors 1988-1991 All Models
All 1988-1991 Hondas
Part # SL2-310
Description
Notes:
1) You must remove the OEM resistor box and use OBD1 style injector connecting plugs. If your vehicle needs OBD1 style injector clips, please select them from the drop down menu above - additional $19.95.
2) Standard spacers included are for B-Series/H-Series engines. If you need D-Series spacers, please select them from the drop down menu above.
Size Calculation
To determine what size injectors you should use, please visit : RC Engineering's Technical Notes
Specifications
Flow Rate in CC per minute: 310CC/min @ 43.5 PSI
Flow Rate in LB per hour: 30LBS/HR @ 43.5 PSI
Resistance: 12.5 ohms
Voltage: 8-15 Volts, nominal 13.5 Volts
Amperage: 1.0 Amps
Pressure: Min 30PSIG/ Max 100PSIG
Part Number: SL2-310
Spacers/O-rings Included: YES
Warranty: 1 year warranty!
Details
- SL2-310
- SL2-310
- RC Engineering
- New
