Ford Mustang 38lb Fuel Injectors Bosch V8 GT 5.0L 4.6L - Venom - TREperformance.com
Ford Mustang 38lb Fuel Injectors 1986-2004
1986-1995 5.0L Ford Mustang GT, lx and Cobra
1996-2004 Ford Mustang GT
1999/2001 Ford Mustang Cobra (Must change injector plugs - additional $40)
If your vehicle needs OBD1 style injector clips/plugs, please select them from the drop down menu above - additional $45.
Flow Rate in CC per minute: 399CC/min @ 43.5 PSI
Flow Rate in LB per hour: 38LBS/HR @ 43.5 PSI
Resistance: 12.5 ohms
Voltage: 8-15 Volts, nominal 13.5 Volts
Amperage: 1.0 Amps
Pressure: Min 30PSIG/ Max 100PSIG
Part Number: HP-638-8
Injector Plug Style: Bosch EV1 Style
O-Rings Included: Yes
Quantity: Set of 8
Overall Height (in): 3.051
Seat to Seat Height (in): 2.026
Manifold O-ring Outside Diameter (in): 0.576
Fuel Rail O-ring Outside Diameter (in): 0.576
Outside Diameter (in): 0.941
Venom Hi-Flow Fuel Injectors
Balanced and Matched Sets
Venom fuel injectors are 100% flow tested, balanced and matched to within +/- 1.5% of their nominal flow rate.
Pintle and Pintle Seat
Pintle assemblies are matched and blueprinted to increase flow rate and fuel atomization.
Internal O-rings are manufactured of advanced polyelastamer compound which increases resistance to fuel compound and high heat generated by the increased duty cycle.
Molded of aerospace grade material and wound with micro-meter tolerances to decrease activation time at the start of each duty cycle. Encased in Kapton tape and molded to protect against electrical current leaching while under severe load.
Solid copper terminals to increase current flow to the electromagnetic coil. Oversized terminals and guide pins for tighter fit and less terminal corrosion.
Filter Basket and External O-Rings
A mesh filter is used to protect against any fuel contaminates. Manufactured of advanced polyelastamer compound which resists against various oils and racing fuels.
- Item Requires Shipping
- 3.0 lbs.
- W5.0000” x H5.0000” x L5.0000”
- Free Shipping!
- FREE Fast Priority Mail shipping to the USA and it's territories on ALL Fuel Injectors.
